| Place of Origin: | China |
| Brand Name: | REX |
| Certification: | CE |
| Model Number: | RL-550, Deco8, Deco12, Deco15 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | Wooden Case |
| Delivery Time: | 15-25 work days |
| Payment Terms: | T/T |
Cooling and recirculation for Heidelberg,Komori, 可BA,Roland, Akiyama, Mitsubishi, Goss,Solna sheet fed offset printing press machine
Technotrans Baldwin Balcontrol Cooling and recirculation replacement for Heidelberg, Komori, KBA,Roland, Akiyama, Mitsubishi, Goss,Solna,TKS, Taiyo, Iwasaki , Castagnoli , Nebiolo, ect printing machine, Didde VIP web machine and label machine in print factory. It can replace Technotrans refrigeration beta C 170 L Central refrigeration, Chiller Technotrans beta.d , Cooling and recirculation Technotrans Alpha Refrigeration & Recirculation Unit, Technotrans beta.f cooling, Baldwin, Royse, Royce cooler, Royce recirculation and refrigeration, Edelmann Cooling, Varn Kompac III Dampening refrigeration and Cooling and recirculation, Eco Cooling and recirculation, Accel, Alcolor etc.Recirculation & Refrigeration Dampening Device in print factory.
It can be used for the following power supply:
1. 380V 50/60 Hz 3 phase
2. 415V 50/60 Hz 3 phase
3. 220V 50/60 Hz single phase
A transformer is needed if the power supply is not in the above list.
1.Model:RL-550-AZ/AZP/B Technotrans Baldwin Balcontrol Cooling and recirculation replacement with CE certificate
RL-550 Technotrans Baldwin Balcontrol Cooling and recirculation replacement is used for following sheet fed offset printing press machine:
52cm 5 color
65cm 2 color
It is designed for 520mm, less than 6 color printing press machines
Specification:
Tank Capacity:55L
Dimension:560 x 630 x 1050mm
Weight:103Kg
Unit Power:3/PE AC 380V 50Hz 5.0A
Pump Power:380V 50Hz 0.52A
Pump Capacity:180W 46L/Min
Power:380V 50 Hz 4.3A
Cooling Capacity:2400W
Refrigerant:R22 or R134A
Range of Temperature setting :+7°C - +50°C
Operating temperature:+5°C - +36°C
Dampening solution additive control range:1% - 5%
| Product Model | RL-550AZ | RL-550AZP | RL-550B |
| Automatic Temperature Control | Yes | Yes | Yes |
| Automatic Alcohol Distribution | Yes | Yes | No |
| Fountain Solution percentage Additive Control | No | Yes | No |
| Intermediate Water Tank (Bubble Deduction) | Yes | Yes | Yes |
2.Model:Deco8 (Original RL-750-AZ/AZP/B) Technotrans Baldwin Balcontrol Cooling and recirculation replacement with CE certificate
RL-750 Technotrans Baldwin Balcontrol Cooling and recirculation replacement is used for following sheet fed offset printing press:
65cm 4 color
102cm 2 color
It is designed for 740mm, less than 4 color printing press machines.
Specification:
Tank Capacity:75L
Dimension:650 x 680x1250
Weight:143Kg
Unit Power:3/PE AC 380V 50Hz 5.0A
Pump Power:380V 50Hz 0.68A
Pump Capacity:250W 46L/Min
Power:380V 50 Hz 4.3A
Cooling Capacity:4000W
Refrigerant:R22 or R134A
Range of Temperature setting :+7°C - +50°C
Required Operating temperature:+5°C - +36°C
Dampening solution additive control range:1% - 5%
| Product Model | RL-750AZ | RL-750AZP | RL-750B |
| Automatic Temperature Control | Yes | Yes | Yes |
| Automatic Alcohol Distribution | Yes | Yes | No |
| Fountain Solution percentage Additive Control | No | Yes | No |
| Intermediate Water Tank (Bubble Deduction) |
Yes
|
Yes
|
Yes
|
3.Model:RL-1100-AZ/AZP/B/PB/PB2 Technotrans Baldwin Balcontrol Cooling and recirculation replacement with CE certificate
RL-1100 Technotrans Baldwin Balcontrol Cooling and recirculation replacement is used for following sheet fed offset printing press machine:
74cm 5 color
It is designed for 740mm, less than 5 color printing press machines.
Specification:
Tank Capacity:110L
Dimension:850x 680 x1250mm
Weight:160Kg
Unit Power:3/PE AC 380V 50Hz 5.5A
Pump Power:380V 50Hz 0.68A
Pump Capacity:250W 46L/Min
Power:380V 50 Hz 4.8A
Cooling Capacity:5000W
Refrigerant:R22 or R134A
Range of Temperature setting :+7°C - +50°C
Required Operating temperature:+5°C - +36°C
Dampening solution additive control range:1% - 5%
| Product Model | RL-1100AZ | RL-1100AZP | RL-1100B | RL-1100PB |
| Automatic Temperature Control |
Yes | Yes | Yes | Yes |
| Automatic Alcohol Distribution |
Yes | Yes | No | No |
| Fountain Solution percentage Additive Control |
No | Yes | No | Yes |
| Dual-Pumps system | No | No | No | No |
| Bubble Deduction Intermediate Tank |
Yes | Yes | Yes | Yes |
4. Model:Deco12 (Original RL-1500-AZ/AZP/PB/PB2) Technotrans Baldwin Balcontrol Cooling and recirculation replacement with CE certificate
RL-1500 Technotrans Baldwin Balcontrol Cooling and recirculation replacement is used for following sheet fed offset printing press machine:
102cm 4color
It is designed for 1020mm, less than 5 color printing machines, commercial web machine or single tower newspaper printing press machines.
Specification:
Tank Capacity:140L
Dimension:1150 x 750x 1250mm
Weight:180Kg
Unit Power:3/PE AC 380V 50Hz 6.3A
Pump Power:380V 50Hz 0.68A
Pump Capacity:250W 46L/Min
Power:380V 50 Hz 5.6A
Cooling Capacity:7000W
Refrigerant:R22 or R134A
Range of Temperature setting :+7°C - +50°C
Required Operating temperature:+5°C - +36°C
Dampening solution additive control range:1% - 5%
| Product Model | RL-1500AZ | RL-1500AZP | RL-1500B for commercial web machine or single tower newspaper printing machines | RL-1500PB2 for commercial web machine or single tower newspaper printing machines |
| Automatic Temperature Control |
Yes | Yes | Yes | Yes |
| Automatic Alcohol Distribution |
Yes | Yes | No | No |
| Fountain Solution percentage Additive Control |
No | Yes | Yes | Yes |
| Dual-Pumps system | No | No | No | Yes |
| Bubble Deduction Intermediate Tank |
Yes | Yes | Yes | Yes |
5. Model:Deco15 (Original RL-1800-AZ/AZP/PB2) Technotrans Baldwin Balcontrol Cooling and recirculation replacement with CE certificate
RL-1800 Technotrans Baldwin Balcontrol Cooling and recirculation replacement is used for following sheet fed offset printing press machine:
130cm 4-6color
It is designed for large sheet fed offset press, commercial web machine or double towers newspaper printing press machines.
Specification:
Tank Capacity:180L
Dimension:1250 x750 x 1300mmD
Weight:275Kg
Unit Power:3/PE AC 380V 50Hz 14.4A
Pump Power:380V 50Hz 0.68A
Pump Capacity:250W 46L/Min
Power:380V 50 Hz 13A
Cooling Capacity:12000W
Refrigerant:R22 or R134A
Range of Temperature setting :+7°C - +50°C
Required Operating temperature:+5°C - +36°C
Dampening solution additive control range:1% - 5%
| Product Model | RL-1800AZ | RL-1800AZP | RL-1800PB2 for commercial web machine or double towers newspaper printing machines |
| Automatic Temperature Control |
Yes | Yes | Yes |
| Automatic Alcohol Distribution |
Yes
|
Yes
|
No
|
| Fountain Solution percentage Additive Control |
No | Yes | Yes |
| Dual-Pumps system | No | No | Yes |
| Bubble Deduction Intermediate Tank |
Yes | Yes | optional |
Deco20 for Man Roland M300(CUTOFF : 546mm, Width: 880MM, 5 COLOR, Speed: 40000IPH), Heidelberg 102-10P
